Xianda Leading 5-Axis Bridge Cutters with Precision  and Speed

Product Description:

The Bridge Saw Cutting Machine is a versatile, precision tool for stone processing, handling granite, marble, and large slabs up to 3200mm. Its 0-85° tilting table ensures flexibility, while the diamond blade guarantees clean cuts on hard materials. Electric-powered for consistent performance, it combines robust construction, efficiency, and accuracy, making it ideal for countertops, tiles, and custom projects. A reliable asset for professionals, balancing speed, durability, and quality output.

1. In the Construction Industry

• In large - scale building projects, the 5 - Axis Bridge Stone Cutter plays a crucial role. For example, when constructing luxury hotels or high - end residential buildings, it is used to cut marble and granite slabs precisely. These cut stones are then used for flooring, wall cladding, and decorative elements. The machine's ability to achieve intricate cuts with high accuracy ensures that the final installation fits perfectly, enhancing the aesthetic appeal of the building.
• In commercial construction, such as shopping malls and office buildings, the 5 - Axis Bridge Stone Cutter is employed to create customized stone countertops, stair treads, and balustrades. The high - speed cutting and multi - axis capabilities allow for the efficient production of these components in large quantities while maintaining strict quality standards.

2. For Monument and Memorial Production

• Memorial and monument makers rely heavily on the 5 - Axis Bridge Stone Cutter. It enables them to carve detailed inscriptions and intricate designs on granite and marble monuments. Whether it's a simple headstone or a large, elaborate war memorial, the machine's precision ensures that the final product is a lasting tribute. The ability to cut at various angles and depths makes it possible to create three - dimensional effects, adding a sense of grandeur to these structures.
• In the production of public art installations made of stone, the 5 - Axis Bridge Stone Cutter is used to shape and cut the raw stone materials according to the artist's design. From abstract sculptures to life - sized statues, the machine helps bring the artist's vision to life by providing the necessary precision and flexibility in cutting.

Technicial Parameter

Parameter	Unit	Create 450	Create 600
Blade diameter range	mm	350-450	350-600
Max processing size	mm	3200*2000*120	3400*2000*180
Lifting stroke	mm	300	500
Worktable size	mm	3200*2000	3400*2000
Table tilting degree	°	0-85	0-85
Head rotating degree	°	0-360	0-360
Head tilting degree	°	0-90	0-90
Air speed	m/min	15	15
Repeated accuracy of positioning	mm	0.1mm/1000	0.1mm/1000
Main motor	kw	18.5(Permanent Magnetic Synchronous Motor)	22(Permanent Magnetic Synchronous Motor)
Gross power	kw	26	30
Water consumption	m³/h	3	3
Outline dimension	mm	5600*3600*3500	5800*3650*3900
Gross weight	kg	6000	7500

Support and Services:

- Training sessions for operators to learn how to operate the machine safely and effectively.

- Troubleshooting guidance to address any technical issues that may arise during operation.

- Maintenance support to keep the machine in optimal working condition and maximize its lifespan.

- Software updates and upgrades to enhance the functionality and performance of the machine.

Packing and Shipping:

Description: Our Bridge Saw Cutting Machine is designed for precision cutting of various materials, making it ideal for use in construction and fabrication industries.

Features:

• Powerful motor for efficient cutting
• Precision cutting blade for accurate results
• Sturdy construction for durability

Package Includes:

• Bridge Saw Cutting Machine
• Cutting blade
• Operating manual

Shipping:

We provide worldwide shipping for the Bridge Saw Cutting Machine. Shipping costs may vary based on location and delivery speed. Please contact us for more information on shipping options and rates.
